UL2405 300 V 80 °C PVC Multi-Conductor Cable
UL2405 300 V 80 °C multi-conductor cable, 18–30 AWG. O.D. 3.4–6.6 mm, stranded, up to 6 cores, shielded. UL E170689 cited. Quote on request.
UL · E170689 is cited for this line. Request the issued document before relying on it for a finished-product approval.
Request certificate or datasheet →UL2405 is a PVC-insulated multi-conductor cable manufactured by Xinya Electronic Co., Ltd. It is rated 300 V, 80 °C. The catalogue describes it as a multicore construction. It is supplied in 30 recorded constructions spanning 18–30 AWG, with an overall diameter of 3.4–6.6 mm, cut to the length you order.
UL2405 at a glance
- 18–30 AWG, across 30 listed constructions
- Stranded conductor throughout the documented range
- Insulation wall 0.4–0.46 mm
- Overall diameter 3.4–6.6 mm
- Max. conductor resistance 23.2–381 Ω/km at 20 °C DC (roughly 7.1–116.1 Ω per 1,000 ft)
- All 30 listed rows carry a shield (51/0.12, 55/0.12, 61/0.12)
How UL2405 compares with its nearest alternatives
UL2405 and UL1347 share the 300 V rating and 80 °C temperature rating. Overall diameter runs 3.4–6.6 mm for UL2405 against 2.5–3.6 mm for UL1347. UL1347 is the tighter of the two, so UL2405 is the option to take only when the larger diameter is acceptable. Insulation wall is 0.4–0.46 mm against 0.45–0.48 mm. Size coverage is 18–30 AWG against 16–26 AWG.
UL2405 and UL1185 share the 300 V rating and 80 °C temperature rating. Overall diameter runs 3.4–6.6 mm for UL2405 against 2.1–3.8 mm for UL1185. UL1185 is the tighter of the two, so UL2405 is the option to take only when the larger diameter is acceptable. Size coverage is 18–30 AWG against 16–30 AWG.
Conductor, core count and shielding
Every construction listed for UL2405 is a stranded conductor, which suits harnesses and assemblies that are flexed or routed around a bend. The resistance column gives the maximum permitted value for the conductor at 20 °C DC.
Core counts run from 2 to 6 in the documented range. Overall diameter grows with core count, so the figure to quote for gland, grommet and connector selection is the finished-cable diameter column rather than the single-core insulation diameter.
How to read the UL2405 table
“Insulation O.D. (mm)” is measured over the insulation, not over a jacket, tape or braid. “Jacket O.D. (mm)” is the finished cable diameter, which is the value to quote for gland, grommet and connector sizing. Conductor resistance is stated at 20 °C DC per kilometre — divide by 3.281 for ohms per 1,000 ft.
Questions buyers ask about UL2405
Which sizes of UL2405 are available?
18–30 AWG, across the 30 constructions in the table below. Sizes outside the table can be quoted on request.
Is UL2405 a stranded conductor?
Every construction documented for this line is stranded. Confirm the strand count you need — the “n/mm” figure in the table — because resistance and flexibility both depend on it, and two rows at the same size can differ.
What overall diameter does UL2405 run to?
The documented range is 3.4–6.6 mm. Quote the size, not the style alone, when the diameter has to fit a specific gland, grommet or channel.
Detailed specification table
Manufacturer construction data for UL2405. Values are transcribed from the source specification sheet. Confirm the final construction and order requirements during quotation.
Scroll horizontally to view all specifications
| AWG | Construction | Conductor diameter (mm) | Core count | Insulation thickness (mm) | Insulation O.D. (mm) | Shield | Jacket thickness (mm) | Jacket O.D. (mm) | Max. conductor resistance (Ω/km, 20°C, DC) |
|---|---|---|---|---|---|---|---|---|---|
| 30 | 7/0.10 | 0.30 | 2 | 0.40 | 1.10 | 51/0.12 | 0.48 | 3.40 | 381 |
| 30 | 7/0.10 | 0.30 | 3 | 0.40 | 1.10 | 55/0.12 | 0.45 | 3.50 | 381 |
| 30 | 7/0.10 | 0.30 | 4 | 0.40 | 1.10 | 61/0.12 | 0.45 | 3.80 | 381 |
| 30 | 7/0.10 | 0.30 | 5 | 0.40 | 1.10 | 68/0.12 | 0.45 | 4.10 | 381 |
| 30 | 7/0.10 | 0.30 | 6 | 0.40 | 1.10 | 7510.12 | 0.48 | 4.50 | 381 |
| 28 | 7/0.127 | 0.38 | 2 | 0.41 | 1.20 | 55/0.12 | 0.48 | 3.60 | 239 |
| 28 | 7/0.127 | 0.38 | 3 | 0.41 | 1.20 | 59/0.12 | 0.49 | 3.80 | 239 |
| 28 | 7/0.127 | 0.38 | 4 | 0.41 | 1.20 | 66/0.12 | 0.48 | 4.10 | 239 |
| 28 | 7/0.127 | 0.38 | 5 | 0.41 | 1.20 | 74/0.12 | 0.51 | 4.50 | 239 |
| 28 | 7/0.127 | 0.38 | 6 | 0.41 | 1.20 | 82/0.12 | 0.53 | 4.90 | 239 |
| 26 | 7/0.16 | 0.48 | 2 | 0.41 | 1.30 | 60/0.12 | 0.48 | 3.80 | 150 |
| 26 | 7/0.16 | 0.48 | 3 | 0.41 | 1.30 | 64/0.12 | 0.53 | 4.10 | 150 |
| 26 | 7/0.16 | 0.48 | 4 | 0.41 | 1.30 | 7210.12 | 0.51 | 4.40 | 150 |
| 26 | 7/0.16 | 0.48 | 5 | 0.41 | 1.30 | 80/0.12 | 0.53 | 4.80 | 150 |
| 26 | 7/0.16 | 0.48 | 6 | 0.41 | 1.30 | 88/0.12 | 0.53 | 5.20 | 150 |
| 24 | 11/0.16 | 0.61 | 2 | 0.40 | 1.40 | 64/0.12 | 0.48 | 4.00 | 94.2 |
| 24 | 11/0.16 | 0.61 | 3 | 0.40 | 1.40 | 69/0.12 | 0.52 | 4.30 | 94.2 |
| 24 | 11/0.16 | 0.61 | 4 | 0.40 | 1.40 | 77/0.12 | 0.49 | 4.60 | 94.2 |
| 24 | 11/0.16 | 0.61 | 5 | 0.40 | 1.40 | 86/0.12 | 0.54 | 5.10 | 94.2 |
| 24 | 11/0.16 | 0.61 | 6 | 0.40 | 1.40 | 24/5/0.12 | 0.56 | 5.80 | 94.2 |
| 22 | 17/0.16 | 0.76 | 2 | 0.42 | 1.60 | 7310.12 | 0.63 | 4.70 | 59.4 |
| 22 | 17/0.16 | 0.76 | 3 | 0.42 | 1.60 | 7810.12 | 0.61 | 4.90 | 59.4 |
| 22 | 17/0.16 | 0.76 | 4 | 0.42 | 1.60 | 87/0.12 | 0.60 | 5.30 | 59.4 |
| 22 | 17/0.16 | 0.76 | 5 | 0.42 | 1.60 | 24/5/0.12 | 0.65 | 6.10 | 59.4 |
| 22 | 17/0.16 | 0.76 | 6 | 0.42 | 1.60 | 24/6/0.12 | 0.66 | 6.60 | 59.4 |
| 20 | 26/0.16 | 0.94 | 2 | 0.43 | 1.80 | 82/0.12 | 0.63 | 5.10 | 36.7 |
| 20 | 26/0.16 | 0.94 | 3 | 0.43 | 1.80 | 88/0.12 | 0.64 | 5.40 | 36.7 |
| 20 | 26/0.16 | 0.94 | 4 | 0.43 | 1.80 | 24/5/0.12 | 0.69 | 6.20 | 36.7 |
| 18 | 41/0.16 | 1.18 | 2 | 0.46 | 2.10 | 24/5/0.12 | 0.71 | 6.10 | 23.2 |
| 18 | 41/0.16 | 1.18 | 3 | 0.46 | 2.10 | 24/5/0.12 | 0.70 | 6.40 | 23.2 |
Source specification sheet: 2405.
